Molybdenum Seed Chuck

Name: Molybdenum Seed Chuck
Brand: Longhua Technology Group (Luoyang) Co., Ltd.

Molybdenum seed chuck is a component used in the semiconductor industry, in which it functions as a holder for a silicon wafer or seed crystal during the crystal growth process. A seed chuck is essential in creating high-quality and defect-free crystals. Made from high-purity molybdenum, a refractory metal known for its excellent high-temperature strength and excellent thermal conductivity, these components can withstand the high temperatures and corrosive environments associated with crystal growth.

Contact Us >

Operating Principle Materials

Operating Principle of Molybdenum Seed Chuck

Molybdenum seed chuck is essential in crystal growth processes in semiconductor manufacturing. The operating principle of molybdenum seed chuck is quite straightforward. First, a silicon wafer or seed crystal is attached to the surface of the seed chuck, which acts as a holder. The seed chuck allows the wafer to be precisely positioned in an orientation that is crucial for crystal growth. Then, the seed chuck holds the wafer in place during the crystal growth process while subject to high temperatures and surface tension forces. During the growth process, the seed crystal serves as a nucleus, and atoms attach to its surface, forming a larger crystal. The exact shape of the seed chuck plays a vital role in uniform growth of the crystal, and therefore the performance of the final semiconductor product. As the crystal grows, the seed chuck must maintain precise control over the wafer's orientation and position, ensuring the production of defect-free, high-quality crystals.

Molybdenum Seed Chuck

What Materials Can Be Evaporated with Molybdenum Boats?

Molybdenum boats can be used to evaporate a wide range of materials due to their high melting point, thermal conductivity, and low coefficient of thermal expansion. Metals, semiconductors, ceramic materials, and other non-metallic materials can all be evaporated with molybdenum boats.

For instance, metals such as gold, silver, aluminum, copper, and platinum are commonly evaporated with molybdenum boats for thin film deposition. Many semiconductor materials, including silicon, germanium, gallium arsenide, and indium phosphide, as well as ceramic materials like alumina and zirconia, can also be evaporated with molybdenum boats.

In addition, molybdenum boats are ideal for evaporation of non-metallic materials such as oxides, sulfides, and nitrides. For instance, materials like titanium oxide, aluminium oxide, iron oxide, and zinc sulfide can be evaporated with molybdenum boats.

Overall, the versatility of molybdenum boats makes them useful in evaporating a wide range of materials for various thin film deposition applications.
